110
Appendix
www
.dell.com | support.dell.com
Expansion Bus
Bus type PCI 32 bit
PCI Express x1, x4, and x16
Bus speed PCI: 33 MHz
PCI Express:100 MHz
Bus throughput PCI Express:
x1 slot bidirectional speed - 500 MB/s
x4 slot bidirectional speed - 2 GB/s
x16 slot bidirectional speed - 8 GB/s
PCI
connectors three
connector size 120 pins
connector data width (maximum) 32 bits
PCI Express
connector one x1
connector size 36 pins
connector data width (maximum) 1 PCI Express lane
PCI Express
connector one x4
connector size 98 pins
connector data width (maximum) 4 PCI Express lanes
PCI Express
connector one x16
connector size 164 pins
connector data width (maximum) 16 PCI Express lanes
