Package, Warranty, Part numbering system – Delta Electronics DNT04 User Manual
Page 12: Model list
DS_DNT04SIP3A_09262007
12
PART NUMBERING SYSTEM
DNT 04 S 0A0
R
03 N
F
A
Product
Series
Input Voltage
Numbers
of Outputs
Output
Voltage
Package
Type
Output
Current
On/Off
logic
Option
Code
DNT- 3A/5A
04 - 2.4V~5.5V
S - Single
0A0 -
Programmable
R - SIP
03 - 3A
N- negative
(Default)
P- positive
F- RoHS 6/6
(Lead Free)
A - Standard Function
MODEL LIST
Model Name
Package
Input Voltage
Output Voltage
Output Current
Efficiency
5Vin, 3.3Vdc full load
DNT04S0A0S03NFA
SMD
2.4V ~ 5.5Vdc
0.75V ~ 3.63Vdc
3A
93.5%
DNT04S0A0R03NFA
SIP
2.4V ~ 5.5Vdc
0.75V ~ 3.63Vdc
3A
94%
DNT04S0A0S05NFA
SMD
2.4V ~ 5.5Vdc
0.75V ~ 3.63Vdc
5A
94%
DNT04S0A0R05NFA
SIP
2.4V ~ 5.5Vdc
0.75V ~ 3.63Vdc
5A
93%
CONTACT:
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:
Europe:
Telephone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:
Asia & the rest of world:
Telephone: +886 3 4526107 x6220
Fax: +886 3 4513485
Email:
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta
for its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license
is granted by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these
specifications at any time, without notice
.
