COUNTERTOPS, UPRIGHTS, OVERHEAD CABINETS AND CANTILEVERED SHELVING
Work Centers
FIGURE 9.
FIGURE 10.
FOR EPOXY TOP:
APPLY A BEAD OF SILICONE AROUND THE TOP
FRAME (SEE FIGURE 3) OF THE UNIT AND ON
THE BACKSPLASH SUPPORT BRACKET AND
PLACE COUNTERTOP IN PLACE. SILICONE
BACKSPLASH TO COUNTERTOP AND
BACKSPLASH SUPPORT BRACKET. OPTIONAL
SIDESPLASHES CAN BE SILICONED INTO PLACE
AT THIS TIME. PROCEED TO FIGURE 11.
FOR LAMINATE TOP:
ATTACH BACKSPLASH TO
TOP WITH SUPPLIED
SCREWS. REMOVE
DRAWERS, POSITION TOP,
AND ATTACH TO TOP
FRAME (FIGURE 3) WITH
SUPPLIED SCREWS.
*OPTIONAL SIDESPLASHES
SHOULD ALSO BE
ATTACHED BEFORE TOP IS
ATTACHED TO BASE UNIT.
