Metro Starsys Countertops, Uprights, Overhead CABINETS AND CANTILEVERED SHELVING User Manual
Metro Furniture
Page 1
INST-UPCTB
REV B – 10/14/05
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA 18705
For Product Information Call: 1-800-433-2232
Visit Our Web Site: www.metro.com
COUNTERTOPS, UPRIGHTS, OVERHEAD CABINETS AND CANTILEVERED SHELVING
Work Centers
FIGURE 1.
FIGURE 2.
NOTE:
IF NOT USING
OVERHEAD
UNIT, SEE
FIGURE 2.
NOTE:
SUPPORT BRACKET ONLY
USED WITH EPOXY TOP.
IF USING LAMINATE TOP
CONTINUE TO FIGURE 5.
FOR TOP MOUNTING
WITHOUT AN OVERHEAD
SEE FIGURE 4.
