Metro Starsys Countertops, Uprights, Overhead CABINETS AND CANTILEVERED SHELVING User Manual
Page 4
Page 4
INST-UPCTB
REV B – 10/14/05
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA 18705
For Product Information Call: 1-800-433-2232
Visit Our Web Site: www.metro.com
COUNTERTOPS, UPRIGHTS, OVERHEAD CABINETS AND CANTILEVERED SHELVING
Work Centers
FIGURE 6.
1. ATTACH THE LOOSELY
ASSEMBLED UPRIGHT
STRUCTURE FROM FIGURE 5
TO THE REAR OF THE BASE
UNIT BY ALIGNING THE
HOLES IN THE UPRIGHTS
AND THE BASE BRACKETS.
SECURE WITH 3/8-16
SCREWS AND SQUARE NUTS.
(NOTE: SQUARE NUT FITS
INTO RECESSED SLOT IN
UPRIGHT.)
2. ONCE UPRIGHT
STRUCTURE IS SECURED,
TIGHTEN THE 5/16-18
SCREWS FROM FIGURE 5 TO
SECURE THE
CROSSMEMBERS.
