COUNTERTOPS, UPRIGHTS, OVERHEAD CABINETS AND CANTILEVERED SHELVING
Work Centers
FIGURE 5.
1. MOUNT AN UPRIGHT
CAP TO EACH UPRIGHT
WITH THE SUPPLIED #6 x ½”
PHILLIPS SCREWS.
2. MOUNT CROSSMEMBERS
TO UPRIGHTS WITH THE
SUPPLIED 5/16-18 x 1-1/4
SELF-THREADING SCREWS.
DO NOT FULLY TIGHTEN
SCREWS UNTIL UPRIGHTS
ARE MOUNTED TO THE BASE
UNIT IN FIGURE 6.
