Connecting power supply

WARNING ►Please use extra caution when connecting the power cord, as

incorrect or faulty connections may result in fire and/or electrical shock.
• Only use the power cord that came with the projector. If it is damaged, contact
your dealer to newly get correct one.
• Only plug the power cord into an outlet rated for use with the power cord's

specified voltage range.
• Never modify the power cord. Never attempt to defeat the ground connection
of the three-pronged plug.

.

Connect the connector of the power cord to the AC inlet of the projector.

.

Firmly plug the power cord's plug into the outlet.

CR/P

R

CB/P

B

AUDIO IN

2

AUDIO IN

1

RGB IN

1

RGB IN

2

SD CARD

AUX I/O

DC 5V

0.5A

LAN

CONTR

OL

RGB OUT

AUDIO OUT

USB

VIDEO

S-VIDEO

AC IN

Setting up

AC inlet

Connector
of the power cord
