10

2. Equipment connection and network setting

4) Click “One-Click” button in fig. 2.2.a. Projector is found. Then capture start

button is pushed and real time display is started automatically.

2.2 Network connection using “One-Click-Communication” function

(Continued)

[Wireless LAN connection]
1) When projector network settings such as IP address and subnet mask are

changed, need to return to the projector factory default settings. (9)

2) In case 802.11b/g wireless LAN device is built-in the PC, make the LAN valid

and other network connections invalid. If wireless LAN device is not built in the

PC, connect 802.11b/g wireless LAN device and install device driver to the PC.

(Refer to the user guide for wireless LAN device details.)

3) Start up “MIU Live Viewer”, then the window appears (shown in fig. 2.2.a).

4) Click “One-Click” button as shown in fig. 2.2.a. Then projector will be found

and the capture start button is activated then real time display is started

automatically.

When you need to set the original IP address and SSID other than factory default

settings, need to set up network connection manually.

This section explains how to set up network connection manually.

2.3 Manual network connection setting – Wired LAN -

At first, connecting projector and PC with wired LAN connection to check PC

setting and connection. Next section explains PC settings.

Connecting projector with network using LAN cable, and then set it ready to

communicate with PC.

* Connecting with existing network, contact network administrator.

At last, turn on the projector. This is the end of Equipments connection.

2.3.1. Equipments connection
