2. Equipment connection and network setting

2.3 Manual network connection setting – In case of wired LAN - (Continued)

Fig. 2.3.3.c “Local Area Network (LAN) Settings” window

3) Uncheck all boxes in “Local Area Network (LAN) Settings” window. (Fig. 2.3.3.c)

Check PC and projector are connected properly here. If it is not connected, check

cable connections and settings are properly or not.

1) Start browser in PC and specify following URL, then click “Go” button.

URL: http://(Projector IP address) /

For example, if projector IP address is 192.168.1.10, specify

URL: http://192.168.1.10/

2) After enter your ID and password, if Fig. 2.3.4 appears, it succeeds.

2.3.4 Check connection

Fig. 2.3.4 “Logon Menu”
