Reply Data format
The connection ID (the data is same as the connection ID data on the sending

data format) is attached to the RS-232C commands reply data.

Reply Connection

ID

0x06

1 byte

Reply Connection

ID

0x15

1 byte

Reply

Error code

Connection

ID

0x1C

2 bytes

1 byte

Reply

Data

Connection

ID

0x1D

2 bytes

1 byte

Reply

Status code

Connection

ID

0x1F

2 bytes

1 byte

Reply

Authentication

Error code

Connection

ID

0x1F

0x04

0x00

1 byte

4. Utilize projector – Advanced -
