3.3 System Setup
To install your Repeater/Cross- Repeater system:
1. Switch off all devices.
2. Connect the interconnect cable to the INTERCONNECT socket(s) of the Local Unit and
the Repeater/Cross- Repeater
3. Connect the interconnect cable to the INTERCONNECT socket(s) of the Remote Unit
and the Repeater/Cross- Repeater
If you have bought a Cross Repeater, your device will have two CATx
connectors but only one fiber connector. Possibly you have to swap the
fiber GBIC from one port to the other to make the unit working properly.
To do this, please refer to installation instruction on page 19.
If you have bought a Dual Cross Repeater, your device will have two
CATx connectors and two fiber connectors. The units are marked as
„Local“ or „Remote“. For a correct installation, please refer to
installation instruction on page 19. If you want to upgrade a Cross
Repeater to Dual Cross Repeater, you need to reconfigure the jumper
settings.To do this, please refer to Setup at the Repeater/Cross- Repeater
on page 18.
4. Connect the 5V power supply unit to power the unit.
Only use the power supply originally supplied with this
equipment or a manufacturer-approved replacement.
5. For a dual head system, connect in the same way like described under 2. and 3. the
CATx/Fiber cables for the secondary monitor.
6. Power up the system
