Strobe Connection
Each RED ALERT ® WiFi VoIP Hands-free Telephone includes two solid state relays, as previously
noted. Contact 1 and Contact 2 each allow peripheral equipment, such as beacons, video cameras, and
alarm generators, to be activated when the E
MERGENCY
push button is pressed. The relay can remain
energized for the duration of the emergency call.
In most applications, an output is used to operate a GAI-Tronics Model 530-001/531A Strobe (sold
separately). For connection details, please refer to Figure 17 or the Model 530-001/531A installation
instructions included with the strobe (GTC Pub. 42004-395).
Figure 17. GAI-Tronics Models 530-001 and 531A Strobe Connection Details
