Access panel view – GAI-Tronics ADVANCE System SmartView User Manual Ver 1.3 User Manual
Page 42
Pub. 42004-444B
ADVANCE System SmartView Software User Manual Version 1.3
Page: 40 of 41
f:\standard ioms - current release\42004 instr. manuals\42004-444b.doc
02/11
Access Panel View
Selecting an access panel from the API Card View will take you directly to the detailed Access Panel
View, which shown below.
Figure 43. Access Panel View Screen
Notation Name
Description
Zone Party Lines
Displays the state of the ten system-wide party lines.
Zone Audio Status
Indicates if the access panel is generating or receiving a page.
Also indicates if an alarm is received by the panel.
Zone Fault Status
Detailed information about the state of the panel’s sensors.
There is no further detail associated with this view.
