API Views
To get to the API status information, begin by selecting an API card in the card rack on the System View
screen. There are two levels of detail available on the API card: the API Card View and the Access Panel
View.
Selecting an API card from the card rack will take you to the API View. From the API View, selecting an
access panel displays detailed status information about the access panel selected.
The API Card View screen is shown below:
API Card View
Figure 42. API Card View Screen
Notation Name
Description
Access Panel
This is the representation of the access panel. The handset
matches the current state of the handset in the field (off-hook or
on-hook).
Selecting the access panel will take you to a more detailed view of the access panel. There can be a
maximum of eight access panels on an API card.
