25
Chapter 3 BIOS Description
Central Control Unit
v CPU Clock
This option is used to set the CPU clock.
v CPU:DRAM Frequency Ratio
This option is used to set the DRAM frequency ratio.
v DRAM Frequency
This option is used to show the DRAM frequency.
v DRAM Clock/Timing Control
Press to set the items of DRAM Clock/Timing Control.
Central Control Unit Menu
v [Smart BIOS]
Smart Power LED
Smart debug LED function within power LED. Enable this function, the power
LED status can show the system status of POST process.
Smart Boot Menu
Smart boot menu with a timer to let user to control boot device easily.
Smooth Over Clock
To open smooth over clock function can let over clocking to be more stable.
System Status Power LED Status
Normal on
No Display blinking once (blinking 2 sec., off 2 sec.)
No Memory blinking twice
Post Error Message blinking thrice
