Chapter 2 Installation Instructions
21
925XE7AA Series User Manual
1394 Connectors: F_1394_1, F_1394_2 (optional)
The 1394 expansion cable can be connected to either the front (provided that
the front panel of your chassis is equipped with the appropriate interface) or
rear panel of the chassis.
F_1394_1
+12V
TPB -
TPA -
F_1394_2
1 2
9 10
+12V
TPB +
GND
Empty
TPA +
GND
TPM Connector: TPM
The TPM (Trusted Platform Module ) provides the ability to the PC to run applica-
tions more secure and to make transactions and communication more trustworthy.
To utilize this function, you should purchase additional devices and install the
driver.
TPM
CK_33M_TPM
Empty
L_FRAMEJ
2
1
20
19
GND
ICH_P_PCIRSTJ
NC
L_AD3
3D3V_SYS
L_AD0 NC
GND
NC
LPCPDJ
L_AD2
L_AD1
GND
NC
SERIRQ NC
GND
GND
+12V
TPB -
TPA -
1 2
9 10
+12V
TPB +
GND
Empty
TPA +
