Chapter 2 Installation Instructions
15
925XE7AA Series User Manual
SPDIF coaxial out port
This port connects to external audio output devices with coaxial cable connector.
1394b Port
This digital interface supporting electronic devices such as digital cameras,
scanners, and printers implements IEEE 1394b standard that allows up to 800
Mbps transfer rates, and increase the computer-to-electronic device operational
distance from 4.5 meters to 100 meters. IEEE 1394b maintains backward
compatibility with 1394a(400 Mbps).
USB 2.0 Ports
These four Universal Serial Bus (USB) ports are available for connecting USB
2.0/1.1 devices.
LAN Port2 (-L/-K) (optional)
This port controlled by BCM4401/BCM5788 with PCI interface allows 100M/1G
connection to a Local Area Network (LAN) through a network hub.
LAN Port1 (-K)
This port controlled by BCM5789 controller with PCI Express x1 interface allows
1G connection to a Local Area Network (LAN) through a network hub.
Line in, Line out, Microphone (for 2/6-channel models)
When using a 2-channel sound source, the Line out jack is used to connect to
speaker or headphone; the Line in jack connects to an external CD player, tape
player or other audio device. The Microphone jack is used to connect to the
microphone.
When using a 6-channel sound source, connect the front speaker to the green
audio output; connect the rear speaker to the blue audio output; connect the
center speaker/subwoofer to the red Microphone output.
Line in, Line out, Microphone, Rear, LEF/CEN, Side Jacks (for 8-channel
models)
When using an 8-channel sound source, connect the front speaker to the green
audio output; connect the rear sound speaker to the black audio output; con-
nect the center speaker/subwoofer to the orange audio output; connect the side
sound speaker to the grey audio output.
