Ac signal generator, (g) type only – Floscan Series 9700/97000 Standard Flow GPS Interface System (twin engine model) User Manual
Page 8
08/21/08
7000-065-00G
AC Signal Generator, (G) Type Only
750G/760G, 75TG/76TG, 750G0/760G0, 75TG0/76TG0
850G/860G, 85TG/86TG, 850G0/860G0, 85TG0/86TG0
950G/960G, 95TG/96TG, 950G0/960G0, 95TG0/96TG0
Type “G” Diesel Multifunction Instruments are preset for the correct flow sensor combination. Before installing the instrument,
verify that the switch settings are correct for your application. Flow Sensor types are coded as part of your kit model number.
Recessed “Arrow” Rotary Switch Settings
Switch Position
Flow Sensor
Switch Position
Flow Sensor
0
CAT 265/265
8
233B/233B
1
RTY 265/201
9
233C/233C
2 265/231
A 233D/233D
3 231/231
B 233E/233E
4 201/201
C 233F/233F
5
BOS 231/201
D
Cummins 231*
E
6
All 235/236 &
Cummins 233C*
233 B-C, C-D, D-E, E-F,
and combinations
FloScan Instrument Company, Inc.
Tel:
(206)
524-6625
Fax:
(206)
523-4961
3016 NE Blakeley Street, Seattle, WA 98105
Email:
Http://www.floscan.com
7 233A/233A
F Cummins 233D*
*Cummins Engines with PT pump injection system using one flow sensor in the feed line to the engine.
