MESSAGE DISPLAY

Since the VFD 3X systems use a shared message center for speed and tach messages

both Switch 1 (SW1) and Switch 2 (SW2) are used to cycle through the various messages. Use
SW1 to select different message screens (Mileage, Performance, Tach Bar). Use SW2 to
change between different readings within the same screen (Trip A, Trip B, Service or km/h,
Hours, Hi RPM). If any BIM modules are connected the information will be shown at the bottom
of the Tach Bar screen. Some typical display screens for the message display are:

Mileage screen with the GEAR menu turned ON. (requires optional GSS-2000)

000000 A 000.0

000000 B 000.0

000000 S 0000

P R N O D 2 1

P R N D 2 1

Mileage screen with the GEAR menu shut OFF.

ODOMETR 000000

TRIP A 000.0

TRIP B 000.0

SERVIC 0000

Tach Bar screen

1 2 3 4 5 6 7 8

Km/h 00

Hours 000.0

Hi RPM 0000

Performance Screen

00 0.0 0.0

00 0.0 00

HI 0-60 1/4

Wait, Brake, 4x4, and Engine indicators use reverse image letters in the message display corners when active.

x4 E

Available readings:

odometer reading (0-999,999)
trip A odometer reading (0-9999.9)

trip B odometer reading (0-9999.9)
distance since last service (0-9,999, or ---- when past due) (when enabled)
0-60 mph time in seconds (0-25.5) (when enabled)
high speed recall (0-255) (when enabled)
¼ mile time in seconds (0-25.5) (when enabled)
¼ mile trap speed (0-255) (when enabled)
kph conversion (or mph conversion if kph selected as primary unit)
high RPM recall (0-18,000)
hours system has been on with tach signal (0-999.9)
bar tach readout on message display (0-8,000)
gear shift position indicator (with purchase of optional GSS-2000)
BIM module messages will display in the message display as well

NOTE: In normal operation you have to use Switch 1 (SW1) to reset trip meters, service
counter, hour meter, high RPM, and the various performance timers. A press and hold
will zero the current reading, if resettable.

Odometer

Trip A

Gear position with overdrive

Trip B

Service reading (when enabled)

High speed recall

0-60 time

¼ mile time

Tach Bar (rpm x1000)

Km/h conversion

Hour meter

High RPM recall

Odometer

Trip A

Trip B

Service reading

¼ mile trap speed

Gear position without overdrive
