Dakota Digital LED Tail Lights for 1973-74 Nova LAT-NR380 - Manual

MAN# 650233
INSTALLATION INSTRUCTIONS
LAT-NR380
LED Tail Lights for 1973-74 Nova.
MAN# 650233
Kit Includes:
Installation:
1. Remove the tail light assembly from the vehicle by removing the original bulb sockets from the
housing. Then remove the housing hardware so it can be removed from the car. Remove the
housings from the vehicle carefully so the housing to body gaskets are not damaged.
2. Next remove the lens. The lens has tabs locking it into the plastic housing. Pry the tabs gently
with a screwdriver to remove lens.
3. Now is a good time to clean the lens and housing. If lenses are in bad shape a new set is
recommended.
4. Remove the mounting plate from the bottom of the assembly which is attached with two 3/8” 6-
32 machine screws. The LED assembly is fastened to the mounting block on a slotted hole as
shown in the picture below. This will normally be secured in the center of the slot but can be
adjusted up or down to move the tail light focus.
