INSTALLATION INSTRUCTIONS
LAT-NR162
LED Tail Lights for ’66 Impala/Caprice and ’67 Caprice
MAN#650160
Kit Includes:
Installation:
’66 Impala
’66 Caprice
’67 Caprice
1. Remove the original bulb connector from the back side of the housing.
2. Remove the light bulb.
3. Remove the tail light housing from the car. There are nuts inside the trunk on the back side of
the housing.
4. Remove the chrome trim plate and tail light lens. These screws are on the back side of the
housing.
5. Now is a good time to clean the lens and housing. If lenses are in bad shape a new set is
recommended.
