Mains Operation And Leakage Power
The mains power consumption as well as the leakage power is stated for driving the power amplifier at
different levels. All the values were measured at nominal load via the 100 V output with two channels
driven. The shown values differ only slightly when the appliance is operated at different nominal output
voltages or in the Direct Out mode.
mains operation at the 100
V output
Umains[V] Imains [A] Pmains
[VA]
Pmains [W] Pout [W] Pv [W] BTU/hr
DPA 4245
idling 230V 0,34 78 47 — 47 160
normal operation (-10 dB) 230V 2,76 635 490 70 420 1430
alarm (-3 dB) 230V 5,54 1274 1040 352 688 2347
nominal conditions 230V 7,45 1714 1420 700 720 2456
DPA 4260
idling 230V 0,57 131 80 — 80 273
normal operation(-10 dB) 230V 3,66 842 655 101 554 1890
alarm (-3 dB) 230V 7,34 1688 1370 506 864 2948
nominal conditions 230V 9,86 2268 1900 1000 900 3070
initial current inrush for both models: < 38 A
Pmains[VA] = apparent power Umains*Imains, Pmains[W] = active power, Pout[W] = output power,
Pv[W] = leakage power, 1BTU = 1055.06 W/s
Fuses
location pos. utilization value dimensions standard
rear panel DPA 4245 —- mains fuse 230V~ AC T8A 250V 5 x 20 mm IEC 127
rear panel DPA 4245 —- mains fuse 230V~ AC T10A 250V 5 x 20 mm IEC 127
print 84171/1 F1 power supply T1A 250V 5 x 20 mm IEC 127
print 84171/1 F2 power supply T1A 250V 5 x 20 mm IEC 127
Extension Kits For The DPA 4245 And The DPA 4260:
NRS 90208 balanced input (input transformer for a single channel)
NRS 90235 1 pair of rack-mount ears
