Mechanical Installation 2-4
1. Carefully uncrate the display. Look each side of the display over for
possible damage during shipping.
2. Following the guidelines described in Section 2.4, lift the display into
position on the support structure.
3. Weld or use ½" Grade-5 bolts and hardware to secure the clip angles to the
support structure as shown in Drawing B-172745 or B-172746.
4. Refer to Section 3 for information on routing power and signal.
5. After installation is complete, carefully inspect the display for any holes
that may allow water to seep into the display. Seal any openings with
silicone. If the eyebolts on the top of the display have been removed, plug
the holes with bolts and the rubber-sealing washer that was removed with
the eyebolt.
2.6 Optional Temperature Sensor
If a temperature sensor will be used with your display, see Appendix C for mounting
and signal connections.
