THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS
DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT
REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS
WRITTEN CONSENT OF DAKTRONICS, INC.
COPYRIGHT 2014 DAKTRONICS, INC.
DAKTRONICS, INC.
AV
DRAWN: DATE:
SHEET JOB NO: REV
AQUATICS SCOREBOARDS
MECHANICAL SPEC; WP-2102
KDRAGT 24 MAR 14
P 1153 E 10 A
1=40
KDRAGT
1168229
00
0'-6" [152mm]
0'-1 5/8" [43mm]
INVERTED
CHANNEL DEPTH
2'-0" [610mm]
9'-0" [2743mm]
0'-6" [152mm]
0'-0 3/4" [19mm]
0'-6" [152mm]
TOP VIEW
FRONT VIEW
BOTTOM VIEW
REAR VIEW
WP-2102
OBROUND @4
HOLE IN TOP IS FOR
PASSING POWER AND
SIGNAL BETWEEN SECTIONS
