Display Specifications
SO-2918-32
DistaView LED Scoreboards
Dimensions
(Height/Width/Depth)
5'-0" (1524 mm) High
10’-0" (3048 mm) Wide
6” (152 mm) Deep
Weight 115 lb (52 kg)
Nominal Digit Size 18" (457 mm)
Digit/Indicator Color Red
Maximum Display Wattage 200 W
Circuit 240 V AC
Amps 0.84 A
Driver number and Address A1 11 SO-2918-32
Display Specifications
TI-2015-31
DistaView LED Scoreboards
Dimensions
(Height/Width/Depth)
2'-4" (711 mm) High
3’-4" (1016 mm) Wide
6” (152 mm) Deep
Weight 36 lb (16 kg)
Nominal Digit Size 24" (610 mm)
Digit/Indicator Color Red
Maximum Display Wattage 150 W
Circuit 120 V AC
Amps 1.25 A
Driver number and Address A1 02 TI-2015-31
2-2 Specifications
