Daktronics BA-1518 Generation IV Multi-Section Outdoor LED Scoreboard - Manual (Page 33)

Specifications 3-19
Model Number of
Sections Dimensions
(Height, Width,
Depth) Weight
Uncrated
(Crated) Digit Size
Digit Color Maximum
Wattage Power Amps
per Line
(Single
Phase) Driver
Number
and
Address
FB-2007 2 Total
Top and
Bottom
H8’-0”, W18’-0”, D6”
(2438 mm, 5486
mm, 152 mm)
H4’-0”, W18’-0”, D6”
(1219 mm, 5486
mm, 152 mm)
560 lb
(254 kg)
980 lb
(445 kg)
ƒ Indicators 8”
(203 mm)
ƒ All Others 24”
(610 mm)
-11: red
-21: amber
300 W 120 V AC 2.5 A A1 12
MS-2009 2 Total
Top and
Bottom
H10’-0”, W25’-0”,
D6”
(3048 mm, 7620
mm, 152 mm)
H5’-0”, W25’-0”, D6”
(1524 mm, 7620
mm, 152 mm) 700 lb
(318 kg)
1330 lb
(603 kg)
ƒ Clock, Score
24” (610
mm)
ƒ All
Others
18” (457
mm)
-11: red
-21: amber
600 W
120 V AC 5.0 A A1 71
A2 72
MS-2009
w/TNMC 2 Total
Top and
Bottom H10’-0”, W25’-0”,
D6”
(3048 mm, 7620
mm, 152 mm)
H5’-0”, W25’-0”, D6”
(1524 mm, 7620
mm, 152 mm) 820 lb
(372 kg)
1558 lb
(707 kg) ƒ Clock, Score
24” (610
mm)
ƒ All
Others
18” (457
mm)
-11: red
-21: amber
900 W
(w/ red
TNMC)
900 W
(w/ amber
TNMC) 120 V AC 7.5 A
7.5 A A1 71
A2 72
