6
Installation
To fit the cooktop into the unit make
an opening of the dimensions given in
the figure, remembering that:
– inside the unit there must be a
space of at least 30 mm between
the bottom of the cooktop and the
top of an appliance or bracket.
– any wall to the side and above the
cooktop must be at least 300 mm
away.
– the wall behind the cooktop must be
at least 50 mm away.
– when there is a wall unit or hood
above the cooktop there must be at
least 650 mm between the cooktop
and the unit or hood.
– the coatings of the walls of the unit
or appliances near the cooktop must
be heat resistant:
“X” protection against heating in
compliance with standards EN
60335-2 6.
Do not install the cooktop near
inflammable materials (e.g.
curtains).
650 mm
450 mm
300 mm
Fig. 6
