SPBD-155F4J1RT

DELTA ELECTRONICS, INC.

3 Revision:

S1

09/20/2006

www.deltaww.com

4. Specification of Receiver

Parameter

Symbol

Min.

Typ.

Max.

Unit

Note

Input Optical Wavelength

λ

IN

1260 1360 nm PIN-PD

Receiver Sensitivity

P

IN

-31

dBm Note

(1)

Input Saturation Power (Overload)

P

SAT

-3 dBm

LOS-Deassert Power

P

A

-

-32

dBm

LOS-Assert Power

P

D

-44 dBm

Note

(2)

LOS Hysteresis

P

A

-P

D

0.5 2 5 dB

Optical Reflectance

-14

dB

Note (3)

Output Data Rise/Fall time

t

r

/t

f

1.5

ns

Note

(4)

S/X Endurance

10

dB

Note (5)

Optical Isolation

25

dB

Note (6)

Note (1). Measured with 1520nm, ER=10dB; BER =<10

-10

@PRBS=2

23

-1 NRZ

Note (2). When LOS asserted, the data output is Low-level (fixed)
Note (3). When the terminal is viewed from the optical path, the reflection toward the optical path of the

optical signal with a central wavelength of 1260nm to 1360nm transmitted to terminal.

Note (4). These are 20%~80% values
Note (5). X=10 MHz, Rectangular BER =10

-10

Note (6). Receiver isolation between 1480nm ~1580nm

0.85

1.20

0.80

1.00

0.50

0.20

0.00

-0.20

A

m

p

lit

ud

e

0.35

0.15

0.00

Time

0.65

Mean level of logical "0"

1.00

Mean level of logical "1"

Optical Pulse Mask with Bessel Filter Specified in ITU-T G.957
