10. EEPROM Serial ID Memory Contents (2-Wire Address A0h)

Address

Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII

00 03 25 20

50 4A

J 75 SN

100

00

125 00

01 04 26 20

51 31

1 76 SN

101

00

126 00

02 07 27 20

52 52

R 77 SN

102

00

127 00

03 00 28 20

53 54

T 78 SN

103

00

128 00

04 08 29 20

54 20

79 SN

104

00

~ 00

05 02 30 20

55 20

80 SN

105

00

255 00

Reserved

for future

use.

06 40 31 20

56 30

81 SN

106

00

07 00 32 20

57 30

82 SN

107

00

08 00 33 20

58 30

83 SN

108

00

09 00 34 20

59 30

84 DC

Note 3

109

00

10 00 35 20

60 06

85 DC

110

00

11 03 36 00 61 0E

86 DC

111

00

12 02 37 00 62 00

87 DC

112

00

13 00 38 00 63 CS1

Note 1

88 DC

113

00

14

0F

39

00

64

00

89 DC

114

00

15 96 40 53 S 65 1A

90 DC

115

00

16 00 41 50 P 66 05

91 DC

116

00

17 00 42 42 B 67 05

92 00

117

00

18 00 43 44 D 68 SN

Note 2

93 00

118

00

19 00 44 2D - 69 SN

94 00

119

00

20 44 D 45 31 1 70 SN

95 CS2

Note 4

120

00

21 45 E 46 35 5 71 SN

96 00

121

00

22 4C L 47 35 5 72 SN

97 00

122

00

23 54 T 48 46 F 73 SN

98 00

123

00

24 41 A 49 34 4 74 SN

99 00

124

00

Notes:
1) Byte 63(CS1): Check sum of bytes 0-62.

2) Byte 68-83 (SN): Serial number.

3) Byte 84-91 (DC): Date code.

4) Byte 95 (CS2): Check sum of bytes 64-94.

2 wire address

1010000 X (A0h)

0

95

Serial ID Defined

by SFP MSA

(96 bytes)

96

127

Vender Specific

(32 bytes)

128

255

Reserved in SFP

MSA

(128 bytes)
