4
Configuring the Printer
The following menu shows the RF Network Configure options.
The Configure menu allows you to set the printer’s IP Address, Subnet Mask,
Gateway, Power Mode, Call/Listen, Protocol, Transfer, and ESS ID.
To exit, press the F button at any time.
Setting the IP Address
This option sets the printer’s IP Address.
1. From the RF Network menu, select Configure.
2. From the Configure menu, select IP Address.
IP Address
192.168.69.62
E R +
Use the A buttons as shown in the following table:
E
Press A to R
Press A to +
Press A to
Saves the setting Scrolls through the
positions from left to right Increments the current
position setting by 1
3. When the setting you want is displayed, press the A button under the E
icon to save the setting. You return to the Configure menu.
IP
Address Subnet
Mask Gateway Power
Mode
Configure
Call/
Listen Protocol
Transfer ESS ID Exit
