Controls, LEDs, and Connectors
MVME721X RTM Installation and Use (6806800M42D) 46
PMC Input/Output Module (PIM) connector J10 routes only power and ground from VME P2
connector. There are no host I/O signals on this connector. The front board routes the PIM from
J14 of PMC Slot 1 to VME P2 rows A and C. The MVME721X RTM routes these signals (pin-for-
pin) from VME P2 to PMC I/O module connector J14.
For installation procedure of PIM, see PMC I/O Module (PIM) Installation .
14 PMC_IO_14 46 PMC_IO_46
15 PMC_IO_15 47 PMC_IO_47
16 PMC_IO_16 48 PMC_IO_48
17 PMC_IO_17 49 PMC_IO_49
18 PMC_IO_18 50 PMC_IO_50
19 PMC_IO_19 51 PMC_IO_51
20 PMC_IO_20 52 PMC_IO_52
21 PMC_IO_21 53 PMC_IO_53
22 PMC_IO_22 54 PMC_IO_54
23 PMC_IO_23 55 PMC_IO_55
24 PMC_IO_24 56 PMC_IO_56
25 PMC_IO_25 57 PMC_IO_57
26 PMC_IO_26 58 PMC_IO_58
27 PMC_IO_27 59 PMC_IO_59
28 PMC_IO_28 60 PMC_IO_60
29 PMC_IO_29 61 PMC_IO_61
30 PMC_IO_30 62 PMC_IO_62
31 PMC_IO_31 63 PMC_IO_63
32 PMC_IO_32 64 PMC_IO_64
Table 3-6 J14 Connector Pin Assignments (continued)
PMC (J14)
Pin Name Signal Description Pin Name Signal Description
