Chapter 4: BIOS Setup
Advanced Boot Security Save & Exit Main
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
HD Audio Azalia Device
HD Onboard PIN Config
Azalia Front Panel
SDIN0 Pin Config
SDIN1 Pin Config
SDIN2 Pin Config
SDIN3 Pin Config
Azalia Snoop
[Enabled]
[Enabled]
[Auto]
[Azalia]
[Azalia]
[Azalia]
[GPIO]
[Disabled]
Advanced Boot Security Save & Exit Main
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Restore on AC Power Loss [Power On]
SB HD Azalia Configuration SB Debug Configuration
HD Audio Azalia Device
Enables or disables the HD Audio Azalia Device function.
HD Onboard PIN Config
Enables or disables HD onboard PIN configuration.
Azalia Front Panel
Enables or disables Azalia Front Panel.
SDIN0 Pin Config to SDIN3 Pin Config
Configures the SDIN0 to SDIN3 as GPIO or Azalia.
Azalia Snoop
Enables or disables Azalia Snoop.
Restore on AC Power Loss
Power Off When power returns after an AC power failure, the
system’s power is off. You must press the Power button
to power-on the system.
Power On When power returns after an AC power failure, the system
will automatically power-on.
