NEXCOM NDiS B842 User Manual
Page 23
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
9
NDiS B862/B842 User Manual
Chapter 2: Jumpers and Connectors
Locations of the Jumpers and Connectors for NDiS B842
The figure below is the main board used in the NDiS B842. It shows the locations of the jumpers and connectors. Both NDiS B862 and NDiS B842 share the
same connectors except that NDiS B862 features 6 HDMIs while NDiS B842 features four HDMIs.
CON1 CN1 SW1
CN9
CN12
CN13
CN17
CN16 CN15
CN18
CN14
CN19
J8 J7
CN8 CN7 CN6
CON2
CON3
LAN1
CN2
CN3
