NDiS B862/B842 User Manual
Chapter 3: System Setup
Ring2
Screw
Ring1
4. Insert the 2 rings (ring 1 then ring 2) into the Wi-Fi antenna jacks.
3. Insert the wireless LAN module into the mini-PCIe slot at a 45 degree
angle until the gold-plated connector on the edge of the module
completely disappears inside the slot. Then secure it with screws.
