Onboard Serial Port 0 Mode

Advanced

Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.

Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.

→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Change the Serial Port 0 mode.
Select or or
mode

Serial Port 0 Configuration

Serial Port

Device Settings

Change Settings

Onboard Serial Port 0 Mode

Onboard Serial Port Max Baud Rate

[Enabled]

IO=3F8h; IRQ=4;

[IO=3F8h; IRQ=4;]

[RS485 AUTO]

[115200 bps]

Onboard Serial Port 0 Mode

RS232
RS422

This field is used to configure the mode of serial port 0 as RS232, RS422,
RS485 or RS485 AUTO.

Selects an optimal setting for the Super IO device.

RS485
RS485 AUTO

Advanced

Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.

Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.

→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Select an optimal setting for
Super IO device.

Serial Port 0 Configuration

Serial Port

Device Settings

Change Settings

Onboard Serial Port 0 Mode

Onboard Serial Port Max Baud Rate

[Enabled]

IO=3F8h; IRQ=4;

[IO=3F8h; IRQ=4;]

[RS485 AUTO]

[115200 bps]

Change Settings

IO=3F8h; IRQ=4;

IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;

IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;

IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;

IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;

Change Settings
