Chapter 4: BIOS Setup
Super IO Configuration
This section is used to configure the serial ports.
Super IO Chip
Displays the Super I/O chip used on the board.
Advanced
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Set Parameters of Serial Port
O (COMA)
Super IO Configuration
Super IO Chip
 Serial Port 0 Configuration
 Serial Port 1 Configuration
 Serial Port 2 Configuration
 Serial Port 3 Configuration
IT8783F
Serial Port 0 Configuration
This section is used to configure serial port 0.
Advanced
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable or Disable Serial Port
(COM) Serial Port 0 Configuration
Serial Port
Device Settings
Change Settings
Onboard Serial Port 0 Mode
Onboard Serial Port Max Baud Rate
[Enabled]
IO=3F8h; IRQ=4;
[IO=3F8h; IRQ=4;]
[RS485 AUTO]
[115200 bps]
Serial Port
This field is used to enable or disable the serial port.
