background image

Description

Type

Parameter

Specifies the

EXTCLK[3..0]

port connectivity. Values are

PORT_USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_EXTCLK[]

Specifies the

EXTCLKENA[3..0]

port connectivity. Values

are

PORT_USED

or

PORT_UNUSED

. If omitted, the default is

PORT_UNUSED

.

String

PORT_EXTCLKENA[]

Specifies the

FBIN

port connectivity. Values are

PORT_USED

or

PORT_UNUSED

. If omitted, the default is

PORT_UNUSED

.

String

PORT_FBIN

Specifies the

FBOUT

port connectivity. Values are

PORT_

USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_FBOUT

Specifies the

INCLK[1..0]

port connectivity. Values are

PORT_USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_INCLK[]

Specifies the

LOCKED

port connectivity. Values are

PORT_

USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_LOCKED

Specifies the

PFDENA

port connectivity. Values are

PORT_

USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_PFDENA

Specifies the

PHASECOUNTERSELECT

port connectivity.

Values are

PORT_USED

or

PORT_UNUSED

. If omitted, the

default is

PORT_UNUSED

.

String

PORT_PHASECOUNTERSELECT

Specifies the

PHASEDONE

port connectivity. Values are

PORT_

USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_PHASEDONE

Specifies the

PHASESTEP

port connectivity. Values are

PORT_

USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_PHASESTEP

Specifies the

PHASEUPDOWN

port connectivity. Values are

PORT_USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_PHASEUPDOWN

Specifies the

PLLENA

port connectivity. Values are

PORT_

USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_PLLENA

Specifies the

SCANACLR

port connectivity. Values are

PORT_

USED

or

PORT_UNUSED

. If omitted, the default is

PORT_

UNUSED

.

String

PORT_SCANACLR
