Rapid Spanning Tree
PSSnet SHL - Redundancy Configuration
Pilz GmbH & Co. KG, Felix- Wankel Str. 2, 73760 Ostfildern
4.7 Combination of RSTP and MRP
81
Activate RSTP at the ports here using S1 as an example.
Configure globally here using S1 as an example:
– the RSTP priority
– global operation
– the MRP compatibility mode
Configure all the participating devices in accordance with the table.
Connect the redundant RSTP connection.
enable Switch to the Privileged EXEC mode.
configure Switch to the Configuration mode.
interface 1/1 Switch to the Interface Configuration mode of
interface 1/1.
spanning-tree port mode Activate RSTP at port.
exit Switch to the Configuration mode.
interface 1/2 Switch to the interface configuration mode for
port
1.2.
spanning-tree port mode Activate RSTP at port.
exit Switch to the Configuration mode.
interface 1/3 Switch to the interface configuration mode for
port
1.3.
spanning-tree port mode Activate RSTP at port.
exit Switch to the Configuration mode.
spanning-tree mst priority 0
4096 Set the RSTP priority to the value 4096.
spanning-tree Activate RSTP operation globally.
spanning-tree stp-mrp-mode Activate MRP compatibility.
