09 Maintenance and specifications
Fuses 09
344 * Option/accessory, for more information, see Introduction.
Engine compartment, upper
Engine compartment, front
Engine compartment, lower
Positions
These fuses are all located in the engine com-
partment box. Fuses in
are located under
.
NOTE
• Fuses 16 – 33 and 35 – 41 may be
changed at any time when necessary.
• Fuses 1 – 15, 34 and 42 – 44 are relays/
circuit breakers and should only be
removed or replaced by a trained and
qualified Volvo service technician.
• There is a special fuse removal tool on
the underside of the cover.
Pos Function A
Circuit breaker 50
Circuit breaker 50
Circuit breaker 60
Circuit breaker 60
Pos Function A
Circuit breaker 60
–
–
Headlight washers* 20
Windshield wipers 30
–
Climate system blower 40
–
ABS pump 40
ABS valves 20
–
Active Bending Lights-
headlight leveling* 10
Central electrical module 20
ABS 5
Speed-dependent steering
force* 5
Pos Function A
Engine Control Module
(ECM), transmission, SRS 10
Heated washer nozzles* 10
-
Lighting panel 5
-
-
-
Relay - engine compart-
ment box 5
Auxiliary lights* 20
Horn 15
Engine Control Module
(ECM) 10
Automatic transmission
control module 15
A/C compressor 15
Coils-A/C compressor 5
