Volvo 2013 XC70 - Manual (Page 285)

07 During your trip
Cargo area
07
283
Attaching the cassette(s)
The two-sections of the net are attached to the
rear side of the rear seat backrest. The cas-
settes have different widths, and the widest
section should be mounted on the right side
(seen from the rear of the vehicle).
1. Fold down the rear seat backrests.
2. Align the cassette’s mounting rail above
the mounting brackets on the backrest
.
3. Slide the cassette onto the mounting
brackets
.
4. Return the backrest to the upright position.
Using the net(s)
G018246
With the backrests upright
The net is pulled up from the cassette and locks
in position after approximately 1 minute.
Pull up the right side of the net by grasping
its strap.
Insert the net’s rod in the retaining bracket
on the right side near the ceiling and press
it forward. It will click into place.
Extend the left section of the rod and insert
it in the bracket on the left side of the cargo
compartment. Press it forward until it clicks
into place.
Pull up the left side of the cargo net and
secure it on the rod.
NOTE
• The net can be fastened in the same
way if the rear seat backrests are folded
down. In this case, use the retaining
brackets near the ceiling, above the
front seats.
• The front passenger's seat backrest
can also be folded down for carrying
long objects, see page 84.
Removing the cargo net cassettes
1. Retract the net(s) in the reverse order.
2. Fold the entire rear seat backrest down.
3. Slide the cassettes outward until they
release from the mounting brackets.
WARNING
• When not in use, return the cassettes to
their storage compartment under the
cargo area floor.
• Objects in the cargo area should be
securely anchored, even if the cargo net
is correctly installed and in use.
