Optical Characteristics
(V
CC
=3.135V to 3.465V, Data Rate=8.5Gb/sec, PRBS=2 7 -1 NRZ, 50/125 µm MMF)
Parameter Symbol Min. Typ. Max. Unit Note
Transmitter
Output Optical Power (Avg.)
P
O
-8.2 -1.8 dBm
Optical Modulation Amplitude OMA 302 µW 1
Center Wavelength 840 850 860 nm
Spectral Width (RMS) 0.65 nm
Optical Rise/Fall Time (20% - 80%) t
r
/ t
f
50/50 ps 2
RIN
12
OMA -128 dB/Hz 3
Output Eye
Complies with the ANSI FC-PI-4 Rev. 6.01 specification, and is class
1 laser eye safety
Receiver
Sensitivity in OMA
@8.5Gbps
@4.25Gbps
@2.125Gbps
P
IN
76
61
49
µW 4
Input Optical Wavelength λ 840 850 860 nm
Average Received Power, max Rmax 0 dBm
LOS-De-asserted (Avg.) P
D
-14 dBm
LOS-Asserted (Avg.) P
A
-30 dBm
LOS-Hysteresis P
D
-P
A
0.5 dB
Optical Return Loss ORL 12 dB
Link Length
Data Rate/Standard Fiber Type
Modal Bandwidth
@850nm (MHz*km)
Distance Range(m)
Notes
.
62.5/125
µm MMF 200 0.5 to 21 5
50/125
µm MMF 500 0.5 to 50 5
50/125
µm MMF 900 0.5 to 90 5
50/125
µm MMF 1500 0.5 to 120 5
8.5Gbps
50/125
µm MMF 2000 0.5 to 150 5
Notes:
1. Equivalent extinction ratio specification for Fiber Channel. Allows smaller ER at higher average power.
2. Measured at nominal data rate. These are unfiltered 20%~80% values.
3. Transmitter Dispersion Penalty is measured using the methods specified in the IEEE standard 802.3-2005 Clause
52 except that the transversal filter differential delay is 33 ps.
4. The sensitivity is tested at a BER of 1×10 -12 or better with an input signal consisting of 2 7 -1 NRZ PRBS.
5. Distance, shown in the “Link Length” table, are calculated for worst case fiber and transceiver characteristics
based on the optical and electrical specifications shown in this document using techniques utilized in IEEE 802.3.
In the nominal case, longer distances are achievable.
