LCP-8500A4EDR
Preliminary
DELTA ELECTRONICS, INC.
2 2008/7/16
Rev. 0A
www.deltaww.com
Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature T
S
-40 85 ºC
Supply Voltage V
CC
0 4 V
Relative Humidity RH 5 95 %
Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Case Operating Temperature T
C
-5 70 ºC
Supply Voltage V
CC
3.135 3.465 V
Data Rate 8.5 9 Gbps
Electrical Characteristics
(V
CC
=3.135V to 3.465V)
Parameter Symbol Min. Typ. Max. Unit Note
Total Supply Current I
CC
180 300 MA
Transmitter
Differential Input Voltage
Vin,pp 120 1000 mVppd 1
Data Input Rise/Fall Time 15 40 Ps 2
Transmitter Disable Input-High V
DISH
2 V
CC
+0.3 V
Transmitter Disable Input-Low V
DISL
0 0.8 V
Transmitter Fault Output-High V
TXFH
2 V
CC
+0.3 V
Transmitter Fault Output-Low V
TXFL
0 0.8 V
Receiver
Differential Output Voltage
V
out,pp
300 1000 mVppd 3
Data Output Rise/Fall Time 45 Ps 1
LOS Output Voltage-Low V
LOSH
2 V
CC
+0.3 V
LOS Output Voltage-High V
LOSL
0 0.8 V
V
IL
-0.3 0.8 V 4
RS0, RS1
V
IH
2.0 Vcc+0.3 V
Notes:
1. Internally AC coupled and terminated to 100 Ohm differential load.
2. These are 20%~80% values.
3. Internally AC coupled, but requires a 100 Ohm differential termination at or internal to Serializer/ Deserializer.
4. Shall be pulled low to VeeT with a 30k ohms resistor in the module.
