52
ENVISION 2 COMPACT - 50 HZ INSTALLATION MANUAL
Service Parts
Part Description
Single Speed Vertical Units Dual Capacity Vertical Units
005 017 006 009 012 015
C
ompr
es
sor
Compressor 220-240/50/1 34P593-03 34P561-09 34P640-02 34P641-02 34P642-02 34P643-01
Compressor 380-420/50/3 N/A 34P646-04 34P640-04 34P641-04 34P642-04 34P643-04
Run Capacitor 220-240/50/1 16P002D30 16P002D33 16P002D20 16P002D23 16P002D24 16P002D39
Sound Jacket 92P504A01 92P504A03 92P504A16
Power Harness 11P622A01 11P781-02 11P781-02
Solenoid Harness N/A 11P782-02
V
ariable Speed ECM Mot
or &
B
lowe
r
VS ECM Motor 220-240/50/1 14S551-01 14S553-01 14S551-01 14S552-01 14S553-01
VS ECM Motor 380-420/50/3 14S551-01 14S553-01 14S551-01 14S552-01 14S553-01
VS ECM Blower Housing 53P512B01 53P515B01 53P512B01 53P515B01
VS ECM Harness 11P607B02 11P607B02
VS ECM Power Harness 11P585B02 11P585B02
5-Speed
ECM Mot
or
& Blo
w
e
r 5-Speed ECM Motor 220-240/50/1 14P536-01 14P537-01 14P536-01 14P537-01
5-Speed ECM Motor 380-420/50/3 14P536-03 14P537-03 14P536-03 14P537-03
5-Speed ECM Blower Housing 53P512B01 53P515B01 53P512B01 53P515B01
R
efriger
ation
C
omponents
Air Coil 61P721-41 61P725-41 61P705-41 61S706-41 61S715-41 61P725-41
Coax 62P585-01 62P557-01 62P566-01 62P574-01 62P543-04 62P543-04
TXV 33P608-02 33P619-05 33P619-01 33P619-02 33P619-03 33P619-04
Reversing Valve 33P502-05 33P526-05 33P506-04 33P503-05 33P526-05
Filter Drier 36P500B01 36P500B02 36P500B01 36P500B02
Hot Water Generator 62P516-05 62P516-03 62P516-05 62P516-03
Electrical
C
omponents
Contactor 13P004A03 13P004A03
Transformer 220-240/50/1 15P501-02 15P501-02
Transformer 380-420/50/3 15P511-02 15P511-02
3 Pole Power Block N/A 12P503-06 12P503-06
2 Pole Screw Term. Block 12P500A01 12P500A01
Sensors &
Saf
eties
Freeze Detection Thermistor 12P505B03 12P505B03
HWL Thermistor 12P505B02 12P505B02
High Pressure Switch 35P506B02 35P506B02
Low Pressure Switch 35P506B01 35P506B01
Part numbers subject to change 04/21/14
Part Description
Single Speed Horizontal Units Dual Capacity Horizontal Units
005 017 006 009 012 015
C
ompr
es
sor
Compressor 220-240/50/1 34P593-03 34P561-09 34P640-02 34P641-02 34P642-02 34P643-01
Compressor 380-420/50/3 N/A 34P646-04 34P640-04 34P641-04 34P642-04 34P643-04
Run Capacitor 220-240/50/1 16P002D30 16P002D33 16P002D20 16P002D23 16P002D24 16P002D39
Sound Jacket 92P504A01 92P504A03 92P504A16
Power Harness 11P622A01 11P781-02 11P781-02
Solenoid Harness N/A 11P782-02
V
ariable Speed ECM Mot
or &
B
lowe
r
VS ECM Motor 220-240/50/1 14S551-01 14S553-01 14S551-01 14S552-01 14S553-01
VS ECM Motor 380-420/50/3 14S551-01 14S553-01 14S551-01 14S552-01 14S553-01
VS ECM Blower Housing 53P512B01 53P515B01 53P512B01 53P515B01
VS ECM Harness 11P607B02 11P607B02
VS ECM Power Harness 11P585B02 11P585B02
5-Speed
ECM Mot
or
& Blo
w
e
r 5-Speed Motor 220-240/50/1 14P536-01 14P537-01 14P536-01 14P537-01
5-Speed Motor 380-420/50/3 14P536-03 14P537-03 14P536-03 14P537-03
5-Speed Blower Housing 53P512B01 53P515B01 53P512B01 53P515B01
R
efriger
ation
C
omponents
Air Coil 61P720-41 61P731-41 61P729-41 61P709-41 61P710-41 61P717-41
Coax 62P585-01 62P555-01 62P566-01 62P574-01 62P543-04
TXV 33P608-02 33P619-05 33P619-01 33P619-02 33P619-03 33P619-04
Reversing Valve 33P502-05 33P526-05 33P506-04 33P503-05 33P526-05
Filter Drier 36P500B01 36P500B02 36P500B01 36P500B02
Hot Water Generator N/A N/A
Electrical
C
omponents
Contactor 13P004A03 13P004A03
Transformer 220-240/50/1 15P501-02 15P501-02
Transformer 380-420/50/3 15P511-02 15P511-02
3 Pole Power Block N/A 12P503-06 12P503-06
2 Pole Screw Term. Block 12P500A01 12P500A01
Sensors &
Saf
eties
Freeze Detection Thermistor 12P505B03 12P505B03
HWL Thermistor 12P505B02 12P505B02
High Pressure Switch 35P506B02 35P506B02
Low Pressure Switch 35P506B01 35P506B01
Part numbers subject to change. 4/21/14
