ENGLISH
10
7 CONNECTIONS
• Do not plug in the AC cord until all connections have been
completed.
• Be sure to connect the left and right channels properly (left with
left, right with right).
• Insert the plugs securely. Incomplete connections will result in the
generation of noise.
• Note that binding pin plug cords together with AC cords or placing
them near a power transformer will result in generating hum or
other noise.
• Noise or humming may be generated if a connected audio
equipment is used independently without turning the power of this
unit on. If this happens, turn on the power of the this unit.
(1) Connecting the audio components (D-M31 series)
• The ADV-M51 can be used connected in a system with the D-M31 series cassette deck (DRR-M31).
• For instructions on operating the separately sold cassette deck (DRR-M31), refer to their respective operating instructions.
• Only the DRR-M31 cassette deck can be connected directly to the ADV-M51 using system connections.
NOTE:
• This system includes digital circuitry which may cause interference such as
color blotching or changes in the color on TVs. If this happens, move the
system and the TV as far apart as possible.
Connecting the speaker systems
Connect the speaker system for the left channel (the left side as seen from the
front) to the L terminals, the speaker system for the right channel to the R
terminals. Refer to the instructions supplied with the speaker system for details.
Be sure to use speaker systems with an impedance of 6
Ω /ohms or greater.
ADV-M51 DVD
surround
receiver
Speaker system
SC-A3L [D-M51DVS only]
Or commercially available
speaker
FM indoor antenna
(included)
AM loop antenna
(included)
AC CORD
AC 120 V, 60 Hz
The ADV-M51 includes a built-in clock function,
so plug its power cord into a wall power outlet to
which electricity is supplied constantly.
Audio cord
System cords
Speaker cords
Stereo audio cord
DSW-3L (D-M51DVS only) or
commercially available subwoofer with
built-in amplifier
