InfoStation 4-Bay User's Guide - Rev. C01 StorCase Technology, Inc.
Installation 15
Figure 11: Typical Single SCSI Host Connection to InfoStation
(Single-Channel InfoStation with Optional SCSI I/O Repeater Module Installed)
T
PC
T = Terminator
InfoStation 4-Bay
Chassis
SCSI Host
IFS4_18
NOTE: Optional Terminator
Board is available.
Refer to Appendix B
for further information.
Terminate or Cascade
to Another InfoStation
