InfoStation 4-Bay User's Guide - Rev. C01 StorCase Technology, Inc.
Installation 11
Removing a Drive from the Chassis
NOTE: Proper procedure must be followed when removing a drive from the drive bay.
It is the responsibility of the User to ensure that the host does not access the
drive while attempting to remove the drive, and to follow the procedure outlined
below. Failure to do so may result in loss of data and/or damage to the drive
itself!
1. Press and hold the Insert/Remove button (Figure 5) in until the Drive Ready LED
starts to flash (approximately 3 seconds).
2. Drive is ready to be removed when the Drive Ready LED is OFF.
3. Unlock the key lock (if locked) and remove the drive carrier by pulling on carrier handle
(Figures 4 & 7).
Figure 7: Removing the Drive Carrier
Lift Handle
and Pull to
Remove Carrier
from Chassis
IFS4_7
