InfoStation 4-Bay User's Guide - Rev. C01 StorCase Technology, Inc.
Installation 7
INSTALLATION
CAUTION: The InfoStation contains NO USER SERVICEABLE PARTS inside the unit.
Warranty is VOID if any of the modules inside the InfoStation are opened.
Refer ALL servicing to qualified service personnel!
NOTES: Before removing any component from its packaging, discharge any static
electricity by touching a properly grounded metal object.
Daisy-chaining requires the optional SCSI I/O Repeater Module(s). Refer to
Appendix B for further information.
Installing the Drive(s) into the InfoStation
While performing the steps in this section, work on a soft surface to prevent excessive shock
to the drive(s) being installed. Also refer to the manufacturer's documentation provided with
the drive(s).
Drive Preparation
1. Remove the drive from its protective packaging.
2. SCSI Drive Termination - Disable SCSI termination from the drive. Refer to the
documentation provided by the drive manufacturer for the location of these termi-
nators or jumpers.
Refer to section "Typical SCSI Channel Configurations" for further information.
