Introduction 3
InfoStation 4-Bay User's Guide - Rev. C01 StorCase Technology, Inc.
This User's Guide describes the steps required for installing drive(s) into the InfoStation
external expansion chassis. This guide is intended to supplement documentation provided with
the host computer system, the operating system, and the drive(s) to be installed within the
InfoStation.
Features:
Compact enclosure (ideal for desktop applications)
Four (4) removable half-height SCA drive carriers
SCSI Ultra320 drive support
Available in Single or Dual-Channel configuration
Corrosion-resistant steel construction
One (1) high pressure, self-adjusting variable-speed blower (39.5 CFM)
One (1) 250W auto-ranging power supply
Audible alarm
Status indicators at each bay
Optional SCSI I/O Repeater Modules available
Optional SAF-TE Processor Board (factory-installed) available
7-year warranty and free 24/7 technical support
Front Panel
(Figure 2)
• Filler Panel - Allows the installation of future StorCase upgrade products.
• LED(s) - Provide the following information:
Drive Ready - Indicates that the drive is properly installed and ready for ac-
cess.
Drive Activity - Indicates that the drive is being accessed.
Drive Fault - Indicates a drive failure.
