Identification of Carrier
NOTES: Carrier labels are provided (Figure 11).
For quick reference, configuration switch settings are indicated on the carrier
labels.
Use carrier labels (provided) to identify carrier (or drive content). Simply remove label from
backing and affix to the top of the drive cover.
For quick reference, configuration switch settings are indicated on the carrier labels.
Figure 11: Carrier Label
ON
P1
ON
P3
ON
P2
ON
P4
4-POSITION SWITCH
LOCATED AT REAR
OF CARRIER
ENCRYPT
BYPASS
ENCRYPTION
MODE
P1
OFF
ON
66
P2
OFF
ON
DATA RATE (MB/sec)
100
133 OFF
OFF
OFF
OFF
OFF
ON
ON
P4 P3
