Introduction 3
Encrypted DE110 User's Guide - Rev. A01 StorCase Technology, Inc.
Figure 2: DE110 with Encryption Receiving Frame and Carrier
(with 128-bit Electronic Security Key shown)
General Description
WARNING: DO NOT lose your electronic security keys! StorCase does not provide du-
plicate keys, and assumes no responsibility for lost data resulting from lost or
stolen keys.
CAUTION: DO NOT insert the electronic security key into any FireWire port! Doing so can
result in damage to the key! StorCase does not provide duplicate keys, and
assumes no responsibility for lost data resulting from damaged keys.
NOTES: Each set of electronic security keys is unique to its dedicated DE110 carrier/
encrypted drive. Key sets are not interchangeable with other DE110 carrier/
encrypted drives.
For Ultra ATA133 (133MByte/sec) operation, an Ultra ATA133 controller and
hard drive(s), and appropriate 40-pin, 80-conductor cable are required.
Downward compatible with Ultra ATA66/100 drives only (does not support
ATA33 drives).
The StorCase Technology Data Express ® DE110 with DES (Data Encryption Standard) or
TDES (Triple Data Encryption Standard) Encryption is a removable drive carrier and receiving
frame, designed to provide durable and reliable mounting for one (1) low-profile (up to 1" high)
3.5" Ultra ATA133 drive within a 5.25" half-height peripheral slot (Figure 2). It is downward
compatible with Ultra ATA66/100 drives only.
The DES version provides 64-bit security, while the TDES version provides 128-bit security.
Both versions use NIST and CSE-certified algorithms for cryptographic operation. Electronic
security keys are provided with each unit.
The DE110 allows a drive to be removed and transported to another DE110-equipped computer
or expansion chassis, and also provides the ability to secure sensitive data by removing and
storing the drive safely for future use.
